Bison Chuck
Bison Chucks are high precision scroll chucks which
are well suited to work which requires close tolerances.
The Bison Chucks come with two sets of jaws, inside and outside.
The inside jaws are installed when the chuck is shipped.
With the use of spindle nose adaptors, some Bison Chucks can be used
with more lathes than are listed below. An adjustment wrench
and a mounting wrench are supplied with each Bison Chuck.
Price:
$1475.00
Qty:
Part Information:
Part No: 90009-01
Categories:
Chucks
Bison Chuck

Bison Chuck



Bison Chucks are high precision scroll chucks which  are well suited to work which requires close tolerances.
The Bison Chucks come with two sets of jaws, inside and outside.
The inside jaws are installed when the chuck is shipped.
With the use of spindle nose adaptors, some Bison Chucks can be used  with more lathes than are listed below. An adjustment wrench
and a mounting wrench are supplied with each Bison Chuck.

Description
A= Bore diameter of chuck
B= Outer diaeter of faceplate
C= Diameter of chuck base
D= Length of chuck

K= Distance from end of spindle to face of the faceplate

Capacity (all chucks) Inside Jaws Outside Jaws
1.83mm to 60mm 0mm to 114mm
5/64" to 2-3/8" 0" to 4-1/2"



Bison Chuck Part Numbers and Specifications
Chuck Model F U HA HJ/EJ EE EA, K
Chuck Number 90009-01 90009-02 90009-03 90009-04 90009-05 90009-06
A 32mm 32mm 32mm 32mm 32mm 32mm
1-1/4" 1-1/4" 1-1/4" 1-1/4" 1-1/4" 1-1/4"
B 81mm 138mm 138mm 190mm 184mm 272mm
3-3/16" 5-7/16" 5-7/16" 7-1/2" 7-1/4" 10-32/4"
C 101mm 101mm 101mm 101mm 101mm 101mm
4" 4" 4" 4" 4" 4"
D 62mm 52mm 52mm 55mm 56mm
2-7/16" 2-1/16" 2-1/16" 2-3/16" 2-1/4"
X 13.65mm 10.16mm 19.05mm 15.01mm 14.10mm 13.34mm
.5375" .400" .750" .591" .555" .525"



Faceplate Mounting Screws and Wrenches
Lathe Model F U HA HJ/EJ EE EA,K
Mounting Screw 7146 7148 7147 7147 7145 71456
Wrench 52045-187 52045-187 52045-187 52045-187 52045-250 52045-250
